Sick 1128736, 3D Belt Pick Ruler3000 Bundle
EAN:
Hst.-Teile-Nr.:
Bestell-Nr.:
Typ
3D Belt Pick Ruler3000 Bundle
Inhalt
1 St.
Anzahl
Gesamt
26.175,83 €
zzgl. MwSt.
7,69 €
Nur noch 1 Stück verfügbar
Technische Daten
- Technology: 3D triangulation
- Precalibrated:
- Product category: Streaming, precalibrated
- Shutter technology: GlobalShutter
- Working distance: 430mm... 1,445mm
- Example field of view: 1,200mmx 345mm
- Exposure mode: Linear HDR
- Illumination: Integrated
- Illumination color: Red, laser, Visible, 660nm, 15nm
- Laser class: 2(EN608251:2014 +A11:2021; IEC608251:2014, Complies with the FDA performance requirements for laser products except for conformance with IEC608251 Ed.3., as described in Laser Notice56 dated May 8, 2019.)
- Data synchronization: Free running, encoder triggered, external triggering
- 3D measurement:
- Scatter measurement:
- Reflectance measurement:
- Ambient light suppression:
- Scheimpflug adapter, integrated:
- Width at minimum operating distance: 540mm
- Width at maximum operating distance: 1,680mm
- Maximum height range: 1,015mm
- Task: Detecting Standard objects Detecting Level Measuring Dimension, contour and volume Monitoring and controlling Quality Determining position 3D position determination
- Connection type: Voltage I/O: M12, 17pin male connector Gigabit Ethernet: M12, 8pin socket, Xcoded
- Connector material: M12: Nickelcoated brass
- Supply voltage 24VDC, 10%
- Ripple: 5V pp
- Power consumption: 12W
- Current consumption: 1.5A
- Enclosure rating: IP65 IP67
- Protection class: III
- Housing material: Aluminum
- Housing color: Blue
- Window material: Float glass, antireflective coated
- Weight: 2.3kg
- Dimensions (Lx Wx H): 336mmx 77mmx 138mm
- Image sensor: CMOS sensor from SICK with ROCC technology, M30
- Scan/frame rate: 46,0003D profiles/s, In reduced ROI 7,0003D profiles/s, full format
- Data points/profile: 3,200
- Repeatability: 8m
- Typical resolution: Z resolution (height): 33m... 265m, X resolution (width): 246m... 710m
- Ethernet: UDP/IP
- Data transmission rate: 1Gbit/s
- Configuration software: Stream Setup
- Operating system: Windows 10
- Application programming interface (API): GenAPI, GenTL, Proprietary SICK GenIStream
- Inputs/outputs: 4x HIGH= 10V... 28.8V, configurable
- Encoder interface: RS422 5V, 2x HTL singleended
- Ethernet: UDP/IP
- Data transmission rate: 1Gbit/s
- Shock load: 15g, 3cycles per axis
- Vibration load: 5g, 10Hz... 150Hz (EN600682
- Ambient operating temperature: 0C... +50C
- Storage temperature: 30C... +70C
- ECLASS 5.0: 27310205
- ECLASS 5.1.4: 27310205
- ECLASS 6.0: 27310205
- ECLASS 6.2: 27310205
- ECLASS 7.0: 27310205
- ECLASS 8.0: 27310205
- ECLASS 8.1: 27310205
- ECLASS 9.0: 27310205
- ECLASS 10.0: 27310205
- ECLASS 11.0: 27310205
- ECLASS 12.0: 27310205
- ETIM 5.0: EC001820
- ETIM 6.0: EC001820
- ETIM 7.0: EC001820
- ETIM 8.0: EC001820
- UNSPSC 16.0901: 43211731
