VDB-810G Mini-PCIe GPS (u-blox M8 GPS/QZSS+GLONASS+BeiDou, G-Sensor)
EAN:
Hst.-Teile-Nr.:
Bestell-Nr.:
Datenblatt (PDF)
13 Stück
Neu
Rechnungsstellung für alle Partner-Artikel jetzt direkt durch ConradMenge (Stück)
Ersparnis
Verpackungspreis (zzgl. MwSt.)
1
-
90,61 €
5
2% = 1,93 €
88,68 €
10
4% = 3,86 €
86,75 €
Mengenrabatte variieren je nach Verkäufer
Sie sparen 0,00 €
Anzahl
Gesamt (90,61 € / Stück)
90,61 €
zzgl. MwSt.
& 14 Tage Rückgaberecht inklusive
Highlights & Details
- GPS/QZSS, GLONASS, BeiDou !
- 72-channels !
- -167dBm SuperSense !
- 10 Hz Update Rate !
Technische Daten
- Chipset : u-blox M8
- Frequency : GPS L1 C/A, SBAS L1 C/A, QZSS L1 C/A, GLONASS L1OF, BeiDou B1
- Channels : Supports 72 Channels
- Tracking & Navigation : -167dBm
- Acquisition : -160dBm
- Cold Start (Autonomous) : -148dBm
- Cold Start : 26 sec
- Warm Start : 26 sec
- Hot Start : <1 sec
- Aided Start : <2 sec
- Horizontal Position : Autonomous : <2.5m CEP, SBAS : <2.0m CEP
- Accuracy of Timepulse Signal : RMS 30ns
- Max Navigation : 99% <60ns
- Update Rate : 10Hz (GPS & GLONASS), 18Hz (GPS)
- Velocity : <500 m/s (972 knots)
- Acceleration : <= 4g
- GPS Protocol : NMEA 0183 V4.0, UBX, RTCM2.3
- Type : Intelligent multipath detection and suppression
- Type : Supports AssistNow® Online and Offline, OMA SUPL Compliant
- Type : 3-axis accelerometer
- Operating Temp. : -40ºC to +85ºC
- Storage Temp. : -40ºC to +85ºC
- Peak Supply Current : Max=150mA
- Max Performance : Acquisition =74mA
- Eco Mode : Tracking = 43mA
- Power Input : 3.3V +-10% VDC input
- Dimensions : 51 x 30 (mm)
- Part Number : VDB-810G-000
- Description : Embedded u-blox M8 GPS with G-Sensor Mini PCIe Card
- Schnittstellen
Mini PCIe
USB
- Anzahl USB 2.0
1 x
- UKCA
Ja
Dokumente & Downloads
Datenblatt
Datenblatt 800280745 VDB-810G Mini-PCIe GPS (u-blox M8 GPS/QZSS+GLONASS+BeiDou, G-Sensor)
Beschreibung
Embedded u-blox M8 GPS with G-Sensor Mini PCIe Card
Features :
Concurrent Reception of GPS/QZSS, GLONASS, BeiDou
72-channel u-blox M8 Engine w/ Over 2 Million Effective Correlators
-167dBm SuperSense® Acquisition & Tracking Sensitivity
10 Hz Position Update Rate
Standard Mini PCIe V1.2 Full-Mini Card(USB2.0 Interface)
Time To First Fix (TTFF) : Embedded u-blox M8 GPS with G-Sensor Mini PCIe Card
Features :
Concurrent Reception of GPS/QZSS, GLONASS, BeiDou
72-channel u-blox M8 Engine w/ Over 2 Million Effective Correlators
-167dBm SuperSense® Acquisition & Tracking Sensitivity
10 Hz Position Update Rate
Standard Mini PCIe V1.2 Full-Mini Card(USB2.0 Interface)
Time To First Fix (TTFF) :
Features :
Concurrent Reception of GPS/QZSS, GLONASS, BeiDou
72-channel u-blox M8 Engine w/ Over 2 Million Effective Correlators
-167dBm SuperSense® Acquisition & Tracking Sensitivity
10 Hz Position Update Rate
Standard Mini PCIe V1.2 Full-Mini Card(USB2.0 Interface)
Time To First Fix (TTFF) : Embedded u-blox M8 GPS with G-Sensor Mini PCIe Card
Features :
Concurrent Reception of GPS/QZSS, GLONASS, BeiDou
72-channel u-blox M8 Engine w/ Over 2 Million Effective Correlators
-167dBm SuperSense® Acquisition & Tracking Sensitivity
10 Hz Position Update Rate
Standard Mini PCIe V1.2 Full-Mini Card(USB2.0 Interface)
Time To First Fix (TTFF) :
